Wecon PLC LX3V

Wecon 40 I / O PLC: LX3V-2416MT4H

Wecon 40 I/O PLC  LX3V-2416MT4H

◇Power supply: AC85-265V power,D:DC24V power, 20W rated power output
◇IO:24xDI/16xDO( Transistor-type ),4-channel 100K high-speed pulse output

◇Port:RS422, RS485,2 BD board supported.
◇Protocol: 2N NO PROTOCOL, LX3V PROTOCOL

Wecon 26 I / O PLC: LX3V-1412MT4H

Wecon 26 I/O PLC : LX3V-1412MT4H

◇Power supply: AC85-265V power,D:DC24V power, 20W rated power output
◇IO:14xDI/12xDO( Transistor-type ),4-channel 100K high-speed pulse output

◇Port:RS422, RS485,1 BD board supported.
◇Protocol: 2N NO PROTOCOL, LX3V PROTOCOL

Wecon 14 I / O PLC: LX3V-0806MR

Wecon 14 I/O PLC : LX3V-0806MR

◇Power supply: AC85-265V power,D:DC24V power, 20W rated power output
◇IO:8xDI/6xDO( Relay-type )
◇Port:RS422, RS485,1 BD board supported.
◇Protocol: LX3V-0806MR-A(D)1 ：1S NO PROTOCOL ,

   LX3V-0806MR-A(D)2 ：2N NO PROTOCOL

Wecon 14 I/O PLC : LX3V-0806MT

Wecon 14 I/O PLC : LX3V-0806MT

◇Power supply: A: AC85-265V power,D:DC24V power.50W rated power

◇IO: 8xDI/6xDO(transistor-type),2-channel 100K high-speed pulse output
◇Port:RS422, RS485 and 1 BD board supported.
◇Protocol: LX3V-0806MT-A(D)1 ：1S NO PROTOCOL
  LX3V-0806MT-A(D)2 ：2N NO PROTOCOL

Wecon 60 I/O PLC : LX3V-3624MR2H

Wecon 60 I/O PLC : LX3V-3624MR2H

◇Power supply: AC85-265V power,D:DC24V power, 20W rated power output
◇IO:36xDI/24xDO( Mix-type ),2-channel 100K high-speed pulse output

◇Port:RS422, RS485,2 BD board supported.
◇Protocol: 2N NO PROTOCOL, LX3V PROTOCOL

Wecon 60 I/O PLC : LX3V-3624MT4H

Wecon 60 I/O PLC : LX3V-3624MT4H

◇Power supply: AC85-265V power,D:DC24V power, 20W rated power output
◇IO:36xDI/24xDO( Transistor-type ),4-channel 100K high-speed pulse output

◇Port:RS422, RS485,2 BD board supported.
◇Protocol: 2N NO PROTOCOL, LX3V PROTOCOL

Wecon 60 I/O PLC : LX3V-3624MT

Wecon 60 I/O PLC : LX3V-3624MT

◇Power supply: AC85-265V power,D:DC24V power, 20W rated power output
◇IO:36xDI/24xDO( Transistor-type ),2-channel 100K high-speed pulse output

◇Port:RS422, RS485,2 BD board supported.
◇Protocol: 2N NO PROTOCOL, LX3V PROTOCOL

Wecon 60 I/O PLC : LX3V-3624MR

Wecon 60 I/O PLC : LX3V-3624MR

◇Power supply: AC85-265V power,D:DC24V power, 20W rated power output
◇IO:36xDI/24xDO( Relay-type )

◇Port:RS422, RS485,2 BD board supported.
◇Protocol: 2N NO PROTOCOL, LX3V PROTOCOL

Wecon 48 I/O PLC : LX3V-2424MR2H

Wecon 48 I/O PLC : LX3V-2424MR2H

◇Power supply: AC85-265V power,D:DC24V power, 20W rated power output
◇IO:24xDI/24xDO( Mix-type ),2-channel 100K high-speed pulse output

◇Port:RS422, RS485,2 BD board supported.
◇Protocol: 2N NO PROTOCOL, LX3V PROTOCOL

Wecon 48 I/O PLC : LX3V-2424MT4H

Wecon 48 I/O PLC : LX3V-2424MT4H

◇Power supply: AC85-265V power,D:DC24V power, 20W rated power output
◇IO:24xDI/24xDO( Relay-type ),4-channel 100K high-speed pulse output

◇Port:RS422, RS485,2 BD board supported.
◇Protocol: 2N NO PROTOCOL, LX3V PROTOCOL

Wecon 48 I/O PLC : LX3V-2424MT

Wecon 48 I/O PLC : LX3V-2424MT

◇Power supply: AC85-265V power,D:DC24V power, 20W rated power output
◇IO:24xDI/24xDO( Relay-type ),2-channel 100K high-speed pulse output

◇Port:RS422, RS485,2 BD board supported.
◇Protocol: 2N NO PROTOCOL, LX3V PROTOCOL

Wecon 48 I/O PLC : LX3V-2424MR

Wecon 48 I/O PLC : LX3V-2424MR

◇Power supply: AC85-265V power,D:DC24V power, 20W rated power output
◇IO:24xDI/24xDO( Relay-type )

◇Port:RS422, RS485,2 BD board supported.
◇Protocol: 2N NO PROTOCOL, LX3V PROTOCOL

Wecon 40 I/O PLC : LX3V-2416MR2H

Wecon 40 I/O PLC : LX3V-2416MR2H

◇Power supply: AC85-265V power,D:DC24V power, 20W rated power output
◇IO:24xDI/16xDO( Relay-type ),2-channel 100K high-speed pulse output

◇Port:RS422, RS485,2 BD board supported.
◇Protocol: 2N NO PROTOCOL, LX3V PROTOCOL

Wecon 40 I/O PLC : LX3V-2416MT

Wecon 40 I/O PLC : LX3V-2416MT

◇Power supply: AC85-265V power,D:DC24V power, 20W rated power output
◇IO:24xDI/16xDO( Transistor-type ),2-channel 100K high-speed pulse output

◇Port:RS422, RS485,2 BD board supported.
◇Protocol: 2N NO PROTOCOL, LX3V PROTOCOL

Wecon 40 I/O PLC : LX3V-2416MR

Wecon 40 I/O PLC : LX3V-2416MR

◇Power supply: AC85-265V power,D:DC24V power, 20W rated power output
◇IO:24xDI/16xDO( Relay-type )

◇Port:RS422, RS485,2 BD board supported.
◇Protocol: 2N NO PROTOCOL, LX3V PROTOCOL

Wecon 32 I/O PLC : LX3V-1616MR2H

Wecon 32 I/O PLC : LX3V-1616MR2H

◇Power supply: AC85-265V power,D:DC24V power, 20W rated power output
◇IO:16xDI/16xDO( Mix-type ),2-channel 100K high-speed pulse output

◇Port:RS422, RS485,2 BD board supported.
◇Protocol: 2N NO PROTOCOL, LX3V PROTOCOL

Wecon 32 I/O PLC : LX3V-1616MT4H

Wecon 32 I/O PLC : LX3V-1616MT4H

◇Power supply: AC85-265V power,D:DC24V power, 20W rated power output
◇IO:16xDI/16xDO( Transistor-type ),4-channel 100K high-speed pulse output

◇Port:RS422, RS485,2 BD board supported.
◇Protocol: 2N NO PROTOCOL, LX3V PROTOCOL

Wecon 32 I/O PLC : LX3V-1616MT

Wecon 32 I/O PLC : LX3V-1616MT

◇Power supply: AC85-265V power,D:DC24V power, 20W rated power output
◇IO:16xDI/16xDO( Transistor-type ),2-channel 100K high-speed pulse output

◇Port:RS422, RS485,2 BD board supported.
◇Protocol: 2N NO PROTOCOL, LX3V PROTOCOL

Wecon 32 I/O PLC : LX3V-1616MR

Wecon 32 I/O PLC : LX3V-1616MR

◇Power supply: AC85-265V power,D:DC24V power, 20W rated power output
◇IO:16xDI/16xDO( Relay-type )

◇Port:RS422, RS485,2 BD board supported.
◇Protocol: 2N NO PROTOCOL, LX3V PROTOCOL

Wecon 26 I/O PLC : LX3V-1412MR2H

Wecon 26 I/O PLC : LX3V-1412MR2H

◇Power supply: AC85-265V power,D:DC24V power, 20W rated power output
◇IO:14xDI/12xDO( Relay-type )，2-channel 100K high-speed pulse output

◇Port:RS422, RS485,1 BD board supported.
◇Protocol: 2N NO PROTOCOL, LX3V PROTOCOL

Wecon 26 I/O PLC : LX3V-1412MT

Wecon 26 I/O PLC : LX3V-1412MT

◇Power supply: AC85-265V power,D:DC24V power, 20W rated power output
◇IO:14xDI/12xDO( Transistor-type ),2-channel 100K high-speed pulse output

◇Port:RS422, RS485,1 BD board supported.
◇Protocol: 2N NO PROTOCOL, LX3V PROTOCOL

Wecon 26 I/O PLC : LX3V-1412MR

Wecon 26 I/O PLC : LX3V-1412MR

◇Power supply: AC85-265V power,D:DC24V power, 20W rated power output
◇IO:14xDI/12xDO( Relay-type )

◇Port:RS422, RS485,1 BD board supported.
◇Protocol: 2N NO PROTOCOL, LX3V PROTOCOL

Wecon 24 I/O PLC : LX3V-1212MR2H

Wecon 24 I/O PLC : LX3V-1212MR2H

◇Power supply: AC85-265V power,D:DC24V power, 20W rated power output
◇IO:12xDI/12xDO( Mix-type ),2-channel 100K high-speed pulse output

◇Port:RS422, RS485,1 BD board supported.
◇Protocol: 2N NO PROTOCOL, LX3V PROTOCOL

Wecon 24 I/O PLC : LX3V-1212MT4H

Wecon 24 I/O PLC : LX3V-1212MT4H

◇Power supply: AC85-265V power,D:DC24V power, 20W rated power output
◇IO:12xDI/12xDO( Transistor-type ),4-channel 100K high-speed pulse output

◇Port:RS422, RS485,1 BD board supported.
◇Protocol: 2N NO PROTOCOL, LX3V PROTOCOL

Wecon 24 I/O PLC : LX3V-1212MT

Wecon 24 I/O PLC : LX3V-1212MT

◇Power supply: AC85-265V power,D:DC24V power, 20W rated power output
◇IO:12xDI/12xDO( Transistor-type ),2-channel 100K high-speed pulse output

◇Port:RS422, RS485,1 BD board supported.
◇Protocol: 2N NO PROTOCOL, LX3V PROTOCOL

Wecon 24 I/O PLC : LX3V-1212MR

Wecon 24 I/O PLC : LX3V-1212MR

◇Power supply: AC85-265V power,D:DC24V power, 20W rated power output
◇IO:12xDI/12xDO( Relay-type )

◇Port:RS422, RS485,1 BD board supported.
◇Protocol: 2N NO PROTOCOL, LX3V PROTOCOL

Wecon 20 I/O PLC : LX3V-1208MR2H

Wecon 20 I/O PLC : LX3V-1208MR2H

◇Power supply: AC85-265V power,D:DC24V power, 20W rated power output
◇IO:12xDI/8xDO( Mix-type ),2-channel 100K high-speed pulse output

◇Port:RS422, RS485,1 BD board supported.
◇Protocol: LX3V-1208MR2H-A(D)2 ：2N NO PROTOCOL

Wecon 20 I/O PLC : LX3V-1208MT

Wecon 20 I/O PLC : LX3V-1208MT

◇Power supply: AC85-265V power,D:DC24V power, 20W rated power output
◇IO:12xDI/8xDO( Transistor-type ),2-channel 100K high-speed pulse output

◇Port:RS422, RS485,1 BD board supported.
◇Protocol: LX3V-1208MT-A(D)1 ：1S NO PROTOCOL ,

  LX3V-1208MT-A(D)2 ：2N NO PROTOCOL

Wecon 20 I/O PLC : LX3V-1208MR

Wecon 20 I/O PLC : LX3V-1208MR

◇Power supply: AC85-265V power,D:DC24V power, 20W rated power output
◇IO:12xDI/8xDO( Relay-type )
◇Port:RS422, RS485,1 BD board supported.
◇Protocol: LX3V-1208MR-A(D)1 ：1S NO PROTOCOL ,

   LX3V-1208MR-A(D)2 ：2N NO PROTOCOL
